Wax Exposed Assembly

LF Group Shower Control - LV-554-982-LF

ECO-MIX ™ Thermostatic water mixing valve, Copper encapsulated thermostatic assembly with Teflon coated shuttle, Combination checkstops, unions on inlets, wall support, Locking temperature regulating handle, Tempered outlet ball valves, Color coded dial thermometer (0 to140ºF, -10º to 60ºC), Temperature adjustment range, 90-140ºF (32-60ºC) Bottom inlets, back outlet, Factory assembled and tested Valve is certified to meet Low-Lead requirements of wetted surface area containing less than 0.25% lead by weight. All other fittings and components, the sum total of which comprise the wetted surface of this product, contain less than one quarter of one percent of lead by weight.
Downloads
Specification
Inlets 1"
Maximum Flow(GPM) 63
Minimum Flow(GPM) 3
Outlet 1 1/4"
Options
Chrome Plated Finish CP
Megatron Nucleus Installed
